Features
Vibration Isolators | Coil Spring |
---|---|
Battery For Electric Start | Not Included |
Warranty | 2 Year (Limited) |
Weight (Lbs.) | 288 |
Ship Weight (Lbs.) | 328 |
Operating Weight (Lbs.) | 288 |
Dimension No Wheel Kit | 22.2"W x 33.6"L x 16.7"H |
Agency Compliance | CARB (California), EPA, National Park Approved |
Surge Start Watts | 5,500.0 |
Continuous Rated Watts | 5,500.0 |
Prime Rating Watts | 5,500 |
Phase | Single-Phase |
Voltage | 120, 240 |
Rated Amps @ Min Volt (Commonly 120v) | 45.8 |
Rated Amps @ Max Volt (Commonly 240v 1-Phase) | 22.9 |
Frequency | 60 Hz |
Power Factor | 1.0 |
Poles | 2 |
Alternator | Brush |
Voltage Regulation | 1.7% |
Voltage Regulation Type | Digital |
Circuit Breakers | 30 Amp |
Insulation | Class H |
Manufacturer | Cummins |
SKU | 5.5HGJAE-2144 (A063B614), 5.5HGJAE-6757 (A063B613) |
Model Number | QG 5500 |
User's Manual
Specification Sheet
Brochure
Warranty
