DST30P Wheel Balancer + Ranger R980XR Tire Changer + Tape Wheel Weights Combo

This powerful combo pack provides everything you need for a complete and efficient tire service bay. It pairs the Ranger R980XR tire changer and DST30P wheel balancer with a set of adhesive tape weights, giving you a professional-grade setup that's ready to go. This package is the ideal choice for shops looking to save space without compromising on quality or performance.

Included in this Package Deal

DST30P (5140154) QTY 1

• Wheel Balancer / 36 mm Shaft / Six-Second Balancing Times
• Say goodbye to chasing weight with the DST30P wheel balancer. This machine is a huge time-saver, delivering incredibly fast floor-to-floor times. It perfectly calibrates the minimal weight adjustments needed for a flawless balance in just six seconds flat.

R980XR (5140146) QTY 1

• Tire Changer / Swing Arm / 30" Capacity
• The R980XR is a great alternative to the R980AT, offering the same space-saving design without the assist tower. It's the perfect machine for general repairs on a wide variety of tires, including racing tires and pickup truck tires, especially for jobs where the beads won't put up a fight.

Tape Wheel Weights / Combo (5150230) QTY 1

• Adhesive Steel Wheel Weights / Combo / ROLLS (1400 pcs. - 0.25 oz. - 1/2' Wide - 22 lbs.)
• This roll of Quick-Peel adhesive steel wheel weights provides an effective and environmentally friendly solution for balancing wheels. It's designed to help you achieve a precise balance with as little weight as possible.

Specifications

Ranger DST30P Wheel Balancer

• Shipping Weight: 398 lbs. (181 kg)
• Maximum Tire Diameter: 50" (1,270 mm)
• Max. Tire Weight: 150 lbs. (68 kg)
• Wheel Diameter Capacity: 8" - 30" (254 mm - 672 mm)
• Wheel Width Capacity: 1.2" - 20" (30 mm - 508 mm)
• Motor: 1.5 HP, 110/220V, 50 / 60 Hz, 1Ph
• Cycle Time: 6 - 9 Seconds (avg.)
• Working Temperature: -5°C / 27°F - 50°C / 82°F
• Balancing Increments: 0.25 oz (7 gram)
• Balancing Speed: 180 RPM
• Accuracy: +/- 1 gram (.035 oz)
• Data Entry: Manual
• Drive System: Belt Drive
• Wheel Braking: Automatic / Electronic
• Balancing Modes: Dynamic / Static / 3-Alloy
• Cones Included: 3 Standard / 1 Truck
• Resolution: 0.01 ounce, 1.4°
• Style: Auto & Light Truck

Ranger R980XR Tire Changer

• Shipping Weight: 716 lbs. (324 kg)
• Maximum Tire Diameter: 50" (1,270 mm)
• Internal Rim Clamping Capacity: 10" – 30" (254 mm - 762 mm)
• External Rim Clamping Capacity: 9" – 28" (229 mm - 711 mm)
• Bead Breaker Tire Width Capacity (Demounting): 1.5” – 13” (38 mm – 330 mm)
• Turntable Tire Width Capacity (Mounting): 4" – 18" (102 mm – 457 mm)
• Style: Fixed Tower Design
• Assist Type: Single-Tower Assist
• Speed: Standard
• Motor: 3 HP (220 VAC 50-60 HZ)
• Air Requirement: 140-165 PSI (10-11 BAR)
• Drive System Type: Electric / Air
• Wheel Clamping Method: 4 Clamps - Internal / External
• Table Clamping System: Dual Pneumatic Cylinders
• Bead Breaking System: Pneumatic Blade / Dual
• Tower Design: Rigid / Fixed
• Power Assist Towers: N/A
• Bead Seating System: Turbo Blast / Bead Seating
• Shipping Dimensions: 43" x 51" x 44" (1,092 mm x 1,295 mm x 1,117 mm)
